• 4 channel video inputs 25 fps PAL (30 fps NTSC). Connect your existing Security Camera or Camcorder

• 1 channel audio input (ie. connect a microphone)

• Supports 4 cards in one PC for 16 video channels & 4 audio channels

• Adjustable picture size, quality and recording speed

• Support full resolution video (768x576 PAL, 640x480 NTSC)

• Continuous recording during playback

• Adjustable playback speed


Advanced Features:

• Support MPEG4 data compressing format

• Support Pan/Tilt/Zoom Control

• Motion detection recording. Records only when there is activity in the selected region

• Alarm triggered recording. Records when external sensors such as door & window sensors are activated

• Remotely record and monitor through your local computer network, internet or dial up connection


Event Management
Event Types Motion detection, alarm sensor, manual triggered
Event Notification Email / Fax / Phone / Pager / Alarm / Flashing message
E-Map Graphical electronic map enables ease of management and monitoring for placement of alarm device and camera
Motion Detection Sensitivity level and noise tolerance control
Moving object tracking
Definable detection area
Alarm I/O Control of conventional security sensor and alarm device(I/O box not included)
Event Report Routine report with preset scheduler via email

Remote Monitoring
Access Privileges Administrator, Manager, Operator, Remote User
Viewing System HTTP Web browser
Remote Control View camera, record video, control PTZ camera
Voice Communication One quick button for half duplex communication
Connections TCP/IP network, modem dial-up

PTZ Camera Control
Movement Control Pan, Tilt, Zoom
Automatic Cruise 8 preset positions
1 preset camera tour
